Sheet 05.640

Color Imagination · Beam

SMARTBEAM 75

ModelSI-295

The SMARTBEAM 75 is a new stylish 75W LED beam moving head basing on “smaller and better” design philosophy. It’s our brightest, most economic 75W spot into a new housing.

Light source: 75W White LED engine
Power consumption: 105W Power consumption
Power supply: AC100-240V 50/60Hz
Ingress protection: IP20 protection rating
Net weight: 7.9kg

PriceOn request

Prices on request. We confirm the configuration, availability and lead time for each project; quotations exclude installation, programming, freight and VAT unless agreed otherwise.

01VideoManufacturer's video on YouTube

Color Imagination SMARTBEAM 75Open on YouTube

02SpecificationManufacturer's data · 21 groups · 80 values

What this product is, in numbers.

The manufacturer's published values. We confirm the configuration and the values that matter for your project before an order.

01Light Source5

Source: 75W White LED engine
Color Temperature: 7500K; Flicker free operation for broadcast TV and FILM
Life Span: 50000H
The life span may vary depending on several following factors but not limited to: Environmental Conditions, Power/Voltage, Usage Patterns (On-Off Cycling), Control, and Dimming)

02Optics3

A set of high resolution and precise optics

2°Projection angle

Linear electric focus with fine control

03Movement5

PAN movement: 540°(8/16 bit)
TILT movement: 270°(8/16 bit); Fast, quiet, smooth and precise 2-Phase motors; Smooth, fast and precise resolution for PAN/TILT movement with low noise operation; Scan position memory, auto reposition after unexpected movement

04Color System4

1 Color wheel with 12 dichroic colors plus

open (half color mode available)

Variable direction rainbow effect with

speed adjustable

05Gobo System2

1 Static gobo wheel with 10 gobos plus open with dithering effect

Fine control for static gobo wheel

06Prism System3

8-Facet prism with variable speed and direction

Prism indexing

Fine control for prism

Show the full specificationHide the rest of the specification15 more groups · 58 values

07Strobe Effect2

0-25Hz high speed LED shutter/strobe effect with variable speed

Preset variable/random strobe and dimming pulse effect

08Dimming System4

0-100% Smooth linear LED dimming

4 Dimming curve modes, linear/square law/Inv square law/S-curve

3 Dimming speed, smooth/fast/default

Fine control for dimming

09Wash System3

Frost filer system (Hybrid effect for wash)

Even and soft coverage

Fine control for frost filter

10Control System9

13/21 DMX channels USITT DMX-512

DMX512, master-slave, or auto operation

DMX recorder and edit function integrated

RDM available (Remote Device Management)

Art-NET (optional)

Wireless receiver system built-in (optional)

Shielded input signal protection for stable signal without interference

RJ45 etherCON IN/OUT (optional as Art-NET)

3-Pin XLR DMX connectors IN/OUT

11Preset Program1

Auto programs

12Display System5

1.8" TFT LCD display

5 Control buttons

180°Reversible for LCD display

Display OFF

DMX signal monitoring indicator

13Cooling System4

Advanced cooling system integrated with aluminum

Efficient low noise self adjusting fan cooling system

Constant temperature readout and management function

Over temperature protection management

14Power Supply4

Electronic supply with active PFC

AC100-240V 50/60Hz

PowerCON IN/ OUT with fuse

105W Power consumption

15Housing4

High intension moulded fire proof ABS PC; Skeleton made of aluminum and steel metal plates; Two side handles on base
Exterior finish: Black

16Installation2

1*1/4 turn fastening Omega Clamps

1*Safety attachment point

17Operating Condition3

Operating positions: all (device on floor or fixed to a support); -25?? to 45?? ambient temperature; IP20 protection rating

18Compliance7

2014/35/EU - Safety of electrical

equipment supplied at low voltage (LVD)

2014/30/EU -

Electromagnetic Compatibility (EMC)

2011/65/EU - Restriction of the use of

certain hazardous substances (RoHS)

19Weight2

N.W.: 7.9kg
G.W.: 9.6kg

20Dimensions2

Product Dimensions: 170(D)*226(W)*364(H)mm
Packing Dimensions: 280(D)*295(W)*385(H)mm

21Accessories6

Power Cable STANDARD code: QTY: 1PCS

Signal Cable STANDARD code: QTY: 1PCS

Omega STANDARD code: QTY: 2PCS

Safety Cable STANDARD code: QTY: 1PCS

Road Case OPTIONAL code: Available for 2-in-1, 4-in-1, 6-in-1 versions

Clamps OPTIONAL code: QTY: 2PCS

03DescriptionManufacturer's description

What it is.

SMARTBEAM 75

The SMARTBEAM 75 is a new stylish 75W LED beam moving head basing on “smaller and better” design philosophy. It’s our brightest, most economic 75W spot into a new housing. The fixture features a 7500K 75W LED with high intensity and efficiency through a set of high resolution 2° optic system. The PAN/TILT integrates in fast and quiet movement. It offers a full complement of professional characteristics, including static gobo wheel, color wheel, a 8-facet prism, linear electronic focus, frost, 0-100% linear LED dimmer, variable speed shutter/strobe.

The SMARTBEAM 75 supports DMX, RDM (Remote Device Management), Art-Net protocol (optional), wireless system built-in(optional).The fixture’s exterior housing is beautifully balanced design with supremely harmonious interior structure for remarkable control. The sculpted body of the SMARTBEAM 75 achieves more than just a striking look.The fixture is applicable for small-medium scale live concerts, DJ Shows, schools, clubs, weddings, etc.
