Lucky Tone Network Switch with 16 POE Ports POE 16 P 30

ModelPOE 16 P 30

Sixteen10/100/1000M adaptive RJ45 ports support IEEE 802.3af/at standard PoE power supply.

Power supply: AC100~240V 50-60Hz
Dimensions: 440*225*44.mm
Weight: 3kg

PriceOn request

Prices on request. We confirm the configuration, availability and lead time for each project; quotations exclude installation, programming, freight and VAT unless agreed otherwise.

01SpecificationManufacturer's data · 1 group · 11 values

What this product is, in numbers.

The manufacturer's published values. We confirm the configuration and the values that matter for your project before an order.

01Specifications11

Model: POE 16 P 30
Transmission Rate: 10/100/1000Mbps
Max. Power Per Port: 30W; IEEE802.3af/at/bt
Total Power: 400W
Fixed Port: 2*1000Base-X uplink SFP fiber ports (Data) 16*10/100/1000Base-T PoE ports (Data /Power)
Ethernet Port: Port 1-16 support 10/100/1000Base-T auto-sensing, full/ half duplex MDI/ MDI-X self-adaption
Network Protocol: IEEE 802.3 10BASE-T, IEEE 802.3i 10Base-T, IEEE 802.3u 100Base-TX, IEEE 802.3ab 1000Base-T, IEEE 802.3z 1000Base-X, IEEE 802.3x
Switching Capacity: 52Gbps (Non-blocking)
Power Supply: AC100~240V 50-60Hz
Dimension (L*W*H): 440*225*44.mm
Net Weight: 3kg

02DescriptionManufacturer's description

What it is.

Single port power supply up to 30W, total power supply up to 40

Support full-duplex based on IEEE802.3x and half-duplex based on Backpressure.

Support gigabit RJ45 port and gigabit SFP fiber port combination, which enables users toflexibly build networking to meet the needs of various scenarios.
