4-Channel WiFi Audio Amplifier
ModelWF-4120
WF-4120 is a compact 4 x 120W amplifier with WiFi, Bluetooth, USB and AUX inputs. It is designed to turn the traditional passive speakers into multi-functional wireless speakers.
- Output power
- 4*120W (4ohm)
- Weight
- 3.4kg
What this product is, in numbers.
The manufacturer's published values. We confirm the configuration and the values that matter for your project before an order.
01Specifications17
- Model
- WF-4120
- Stereo Mode
- Rated Output Power
- 4*120W (4ohm)
- Input Sensitivity
- 1V(1KHz)
- THD+N
- <0.1%
- SNR
- >90dB
- Frequency Responses
- 20Hz-20KHz -2dB
- Bridge Mode
- Rated Output Power
- 250W(4ohm)
- Input Sensitivity
- 300MV(60Hz)
- THD+N
- <0.1%
- SNR
- >90dB
- Frequency Responses
- 20Hz-200Hz
- Mic
- Input Sensitivity
- 30MV
- THD+N
- <0.1%
- SNR
- >72dB
- Frequency Responses
- 150Hz-20KHz±2dB
- Product Dimensions
- 430x265x44mm
- Net Weight
- 3.4kg
Show the full specificationHide the rest of the specification0 more groups · 0 values
What it is.
Description
WF-4120 is a compact 4 x 120W amplifier with WiFi, Bluetooth, USB and AUX inputs. It is designed to turn the traditional passive speakers into multi-functional wireless speakers. It includes a subwoofer phase switch, with four outputs in stereo mode for stereo sound. In bridged mode, CH1 and CH2 are in subwoofer mode, while CH3 and CH4 are in full-range mode, forming a 2.1 audio system.
Features
- Allow wireless music streaming via WiFi or Bluetooth
- With 4 x 120W stereo speaker outputs
- With USB reader and AUX input for more audio sources
- Can adjust volume of each channel independently
- Supports online music, Internet radio, Airplay, DLNA, Amazon Alexa
- Convenient music management by WiiM APP
