Sheet 05.202
Lucky Tone · Loudspeakers
Lucky Tone Rimless Ceiling Speaker CP-506LMT / CP-606LMT / CP-810LMT
ModelCP-506LMT / CP-606LMT / CP-810LMT
Full range yet high quality music and speech reproduction
- Weight
- CP-506LMT: 0.5Kg; CP-606LMT: 0.7Kg; CP-810LMT: 1Kg
PriceOn request
Prices on request. We confirm the configuration, availability and lead time for each project; quotations exclude installation, programming, freight and VAT unless agreed otherwise.
Rimless Ceiling SpeakerPrice on requestRequest a quotation
01Models3 models in the family
Models compared.
| MODEL | CP-506LMT | CP-606LMT | CP-810LMT |
|---|---|---|---|
| Power at 100V | 3/6W | 3/6W | 5/10W |
| Power at 70V | 1.5/3W | 1.5/3W | 2.5/5W |
| SPL( 1W/1M) | 92dB | 92dB | 92dB |
| Max SPL@ 1M | 99dB | 99dB | 101dB |
| Freq. Response | 100Hz-16KHz | 100Hz-18KHz | 100Hz-18KHz |
| Cutout Size | Dia 140mm | Dia 170mm | Dia 210mm |
| Product Size | Dia160x55mm(H) | Dia185x75mm(H) | Dia230x90mm(H) |
| Installation | Inceiling | Inceiling | Inceiling |
| Enclosure Material | ABS | ABS | ABS |
| Weight | 0.5Kg | 0.7Kg | 1Kg |
| Finish | White | White | White |
| Speakers | 5″x1 full range | 6″x1 full range | 8″x1 full range |
02DescriptionManufacturer's description
What it is.
Fast installation range of speaker
Elegant Rimless design
