Sheet 05.146
Lucky Tone · Loudspeakers
High Performance 2-way Rimless Speaker
ModelCR- 62 0LMT / CR- 62 0LM / CR-830LMT / CR-830LM
Colorful Poly woofer produces smooth and natural HiFi sound
- Weight
- CR- 62 0LMT: 1.0KG; CR- 62 0LM: 0.8KG; CR-830LMT: 1.25KG; CR-830LM: 0.9KG
PriceOn request
Prices on request. We confirm the configuration, availability and lead time for each project; quotations exclude installation, programming, freight and VAT unless agreed otherwise.
High Performance 2-way Rimless SpeakerPrice on requestRequest a quotation
01Models4 models in the family
Models compared.
| Model | CR- 62 0LMT | CR- 62 0LM | CR-830LMT | CR-830LM |
|---|---|---|---|---|
| Power at 100V | 15W /7.5W | / | 30W /15W /7.5W | / |
| Recommended Amplifier Power | / | 15W to 125W | / | 20W to 125W |
| Power Peak | 60W at 8 ohm | 60W at 8 ohm | 120W at 8 ohm | 120W at 8 ohm |
| SPL( 1W/1M) | 89dB | 89dB | 89dB | 89dB |
| Max SPL@ 1M | 101dB | 101dB | 104dB | 104dB |
| Freq. Response | 65Hz-20KHz | 65Hz-20KHz | 50Hz-20KHz | 50Hz-20KHz |
| Cutout Size | Dia 170mm | Dia 170mm | Dia 210mm | Dia 210mm |
| Installation | Inceiling | Inceiling | Inceiling | Inceiling |
| Enclosure Material | ABS | ABS | ABS | ABS |
| Weight | 1.0KG | 0.8KG | 1.25KG | 0.9KG |
| Color | White | White | White | White |
| Product Size | Dia 187x87mm(H) | Dia 187x80mm(H) | Dia 235x104mm(H) | Dia 235x93mm(H) |
| Speakers | 1″ x1 (TREBLE) 6″x1(BASS) | 1″ x1 (TREBLE) 6″x1(BASS) | 1″ x1 (TREBLE) 8″x1(BASS) | 1″ x1 (TREBLE) 8″x1(BASS) |
02DescriptionManufacturer's description
What it is.
Elegant Rimless design
Easy and fast installation
Designed for optimal performance in a wide variety of commercial applications
03Documents1 file · 1.4 MB
Documents and files.
Datasheets, manuals, drawings and certificates as the manufacturer publishes them.
Datasheets and manuals01
