ONVIF Network Ceiling Speaker
ModelVOIP-15C/VOIP-15CM(Mic Version)
This ONVIF Network Ceiling Speaker is built for durability and exceptional audio quality, ideal forpublic address, emergency alerts, and broadcasting in schools, hospitals, malls, and transportationhubs.
- Output power
- 15W
- Frequency response
- 100Hz-20kHz
- Power supply
- POE/DC12V
- Weight
- 1.5kg
PriceOn request
Prices on request. We confirm the configuration, availability and lead time for each project; quotations exclude installation, programming, freight and VAT unless agreed otherwise.
ONVIF Network Ceiling SpeakerPrice on requestRequest a quotation
01SpecificationManufacturer's data · 1 group · 15 values
What this product is, in numbers.
PDFSpecifications977 KB
The manufacturer's published values. We confirm the configuration and the values that matter for your project before an order.
01Specifications15
- MODEL
- VOIP-15C/VOIP-15CM(Mic Version)
- Product Type
- Ceiling Speaker
- Rated Power
- 15W
- Network Protocol
- SIP, ONVIF
- Audio Decoding
- MP3, WMA, WAV
- Network Interface
- 10/100Base-TX, RJ45
- SPL(1M/1W)
- 91dB
- Max. SPL
- 103dB
- Frequency Response
- 100Hz-20kHz
- Speaker
- 6″Woofer + 25mm Voice Coil
- Power Supply
- POE/DC12V
- Installation
- In-ceiling Mount
- Material
- Metal
- Product Dimension
- Dia 193*102mm
- Net Weight
- 1.5kg
Show the full specificationHide the rest of the specification0 more groups · 0 values
02DescriptionManufacturer's description
What it is.
This ONVIF Network Ceiling Speaker is built for durability and exceptional audio quality, ideal forpublic address, emergency alerts, and broadcasting in schools, hospitals, malls, and transportationhubs. SIP-enabled with PoE and DC power, they integrate seamlessly with IP systems.
03Documents1 file · 977 KB
Documents and files.
Datasheets, manuals, drawings and certificates as the manufacturer publishes them.
