Lucky Tone Ultra-thin Wall Mount Speaker WSP-512B/W / WSP-512TB/W
ModelWSP-512B/W / WSP-512TB/W
6W/12W output for different application needs.
- Output power
- WSP-512B/W: 12W@8Ω; WSP-512TB/W: 6W/12W@100V
- Frequency response
- 120Hz-20kHz
- Weight
- 1.03kg
PriceOn request
Prices on request. We confirm the configuration, availability and lead time for each project; quotations exclude installation, programming, freight and VAT unless agreed otherwise.
Ultra-thin Wall Mount SpeakerPrice on requestRequest a quotation
01Models2 models in the family
Models compared.
| Model | WSP-512B/W | WSP-512TB/W |
|---|---|---|
| Rated Power | 12W@8Ω | 6W/12W@100V |
| Frequency Response | 120Hz-20kHz | 120Hz-20kHz |
| Sensitivity | 90dB | 90dB |
| Max SPL@ 1M | 101dB | 101dB |
| Panel Material | ABS | ABS |
| Speakers Size | 5.25″ Woofer + 0.5″ Tweeter | 5.25″ Woofer + 0.5″ Tweeter |
| Color | Black | Black |
| Product Size | 270*181*35.6mm | 270*181*35.6mm |
| Net Weight | 1.03kg | 1.03kg |
02DescriptionManufacturer's description
What it is.
Features
- 100V and 8ohm selectable
- Ultra-thin design with only 35.6mm thickness, optimizing space usage.
- Tweeter and mid-low frequency driver deliver clear, bright sound.
- Compact wall-mounted design with a clean appearance.
- Ideal for PA and BGM.
03Documents1 file · 3.3 MB
Documents and files.
Datasheets, manuals, drawings and certificates as the manufacturer publishes them.
