Sheet 05.29
VTRIX · Switchers and KVM
PS18G512
A switcher for HDMI, DisplayPort and USB-C sources with a MultiViewer and 4K transmission over HDBaseT up to 40 m.
- Inputs
- 3 HDMI + DisplayPort + USB-C
- Outputs
- HDMI + HDBaseT
- Video format
- 4K 4:4:4 / 60 Hz
PriceOn request
Prices on request. We confirm the configuration, availability and lead time for each project; quotations exclude installation, programming, freight and VAT unless agreed otherwise.
PS18G512Price on requestRequest a quotation
01SpecificationManufacturer's data · 1 group · 9 values
What this product is, in numbers.
The manufacturer's published values. We confirm the configuration and the values that matter for your project before an order.
01Specifications9
- Inputs
- 3 HDMI + DisplayPort + USB-C
- Outputs
- HDMI + HDBaseT
- Video format
- 4K 4:4:4 / 60 Hz
- Video interface
- HDMI 2.0
- Bandwidth
- 18 Gbps
- Switching
- 0 ms, seamless
- MultiViewer
- Predefined window layouts
- Control
- RS-232
- HDBaseT range at 4K
- 40 m
Show the full specificationHide the rest of the specification0 more groups · 0 values
02DescriptionManufacturer's description
What it is.
- 4K / 60 Hz
- 0 ms
- Presentation
