Sheet 05.387
Lucky Tone · Public address
Lucky Tone Digtal Mixer Amplifiers with Audio Source MA-1000T V2/MA-1000TD V2 / MA-2000T V2/MA-2000TD V2
ModelMA-1000T V2/MA-1000TD V2 / MA-2000T V2/MA-2000TD V2
This series of Amplifier is a multi-function network DSP digital High-Z and low-Z power amplifier which can remotely monitor the status of power amplifier, set compression Controller, limiter, noise gate, parametric equalization, matrix routing, delay and other DSP functions in real time. Simple software interface provides customers with simple setup and operation experience, and a variety of connection methods ensure its good configurability and expandability, suitable for various applications, such as performance center, theatre, gallery, hotel, conference center, shopping center, retail store, restaurant, etc.
- Output power
- MA-1000T V2/MA-1000TD V2: 2*450w at 4ohm; or 1*600W at 8ohm bridged, 1*600W 100V line bridged, 1*350W 70V line bridged; MA-2000T V2/MA-2000TD V2: 4*450w at 4ohm; or 2*600W at 8ohm bridged, 2*600W 100V line bridged, 2*350W 70V line bridged
- Frequency response
- 20 – 20,000 Hz, +/- 0.5dB at 1W, 8ohm
- Dimensions
- 44.5(H) x 483(W) x 330(D) mm
PriceOn request
Prices on request. We confirm the configuration, availability and lead time for each project; quotations exclude installation, programming, freight and VAT unless agreed otherwise.
Digtal Mixer Amplifiers with Audio SourcePrice on requestRequest a quotation
01Models2 models in the family
Models compared.
| MODEL | MA-1000T V2/MA-1000TD V2 | MA-2000T V2/MA-2000TD V2 |
|---|---|---|
| Output Power | 2*450w at 4ohm; or 1*600W at 8ohm bridged, 1*600W 100V line bridged, 1*350W 70V line bridged | 4*450w at 4ohm; or 2*600W at 8ohm bridged, 2*600W 100V line bridged, 2*350W 70V line bridged |
| Output | 100V or 4 – 16ohm, DSP software selectable | 100V or 4 – 16ohm, DSP software selectable |
| Frequency Response | 20 – 20,000 Hz, +/- 0.5dB at 1W, 8ohm | 20 – 20,000 Hz, +/- 0.5dB at 1W, 8ohm |
| THD | Less than 0.1% at 1W to full load | Less than 0.1% at 1W to full load |
| S/N Ratio | 6dBu and 0dBu at 94dB | 6dBu and 0dBu at 94dB |
| Input EQ | 15 Bands | 15 Bands |
| Output EQ | 10 Bands | 10 Bands |
| Cooling | Internal 12VDC fan, extensive heat sinking | Internal 12VDC fan, extensive heat sinking |
| Display | 320*240 res, IPS colored | 320*240 res, IPS colored |
| Dante interface | 2 Channel | 2 Channel |
| Power Requirements | 100-240V AC, 50/60 Hz | 100-240V AC, 50/60 Hz |
| Dimensions | 44.5(H) x 483(W) x 330(D) mm | 44.5(H) x 483(W) x 330(D) mm |
| Built-in Dimensions | 1 U rack 19 inch | 1 U rack 19 inch |
| Finish | Panel: Aluminum plate, black; Case: steel plate, black | Panel: Aluminum plate, black; Case: steel plate, black |
02DescriptionManufacturer's description
What it is.
Features
Flexible Dante Network amplifier with DSP with both 100V line and 8ohm
Software selectable
- Local analog audio input selection
- Built-in DSP digital processor
- Network TCP/IP control for multiple device management
- Support multiple on line modes: USB, TCP/IP, RS232, RS485
- Real-time remote monitoring of power amplifier working status
- Support balanced XLR input and unbalanced RCA input
- Support stereo, bridge, mono, free matrix mode, onebutton switching
