Sheet 05.340
Lucky Tone · IP, SIP and ONVIF
Outdoor Terminals
ModelSIP-TL Outdoor
●Professional SIP terminals working with Lucky Tone SIP microphone, other SIP telephones and devices.
- Power supply
- DC 12V
- Dimensions
- 150 x 190 x 36 mm
- Weight
- 0.7kg
PriceOn request
Prices on request. We confirm the configuration, availability and lead time for each project; quotations exclude installation, programming, freight and VAT unless agreed otherwise.
Outdoor TerminalsPrice on requestRequest a quotation
01SpecificationManufacturer's data · 1 group · 10 values
What this product is, in numbers.
PDFSpecifications3.3 MB
The manufacturer's published values. We confirm the configuration and the values that matter for your project before an order.
01Specifications10
- MODEL
- SIP-TL Outdoor
- Network Communication Protocol
- TCP, ARP, ICMP, DHCP, UDP, DNS, IGMP
- Network Interface
- 10/100Base-TX,RJ45
- Frequency and Sampling Rate
- 8kHz-32 kHz, 16 bit
- Power consumption
- Less than 300mV
- Microphone Frequency Range
- 70Hz~12.5KHz
- Operating Temp.
- -40~80°C
- Weight
- 0.7kg
- Power Supply
- DC 12V
- Dimension
- 150 x 190 x 36 mm
Show the full specificationHide the rest of the specification0 more groups · 0 values
02DescriptionManufacturer's description
What it is.
Features
- ●Adopt high-speed industrial grade chip
- ●Support quiet and noisy environment mode, press to answer or auto answer, hangup on site or remote
- ●Built-in speaker for intercom
- ●With audio output for external active speaker
- ●Can work stand alone without any main control unit
03Documents1 file · 3.3 MB
Documents and files.
Datasheets, manuals, drawings and certificates as the manufacturer publishes them.
04Related products
In the same range.
EQ-339Lucky ToneOutdoor Intercom Terminal with audio and videoSIP-TLO1 V · IP, SIP and ONVIFPower supplyDC12V/1A or PoE
EQ-341Lucky ToneSIP Ceiling Speaker (15W Rated)IPC-615S / IPC-615SPOE · IP, SIP and ONVIFFrequency response100Hz ~ 18KHzDimensionsDia 200 x 90 mmPower supplyIPC-615S: DC 24V; IPC-615SPOE: POE
EQ-338Lucky ToneONVIF Network Wall SpeakerVOIP-60WM/VOIP-60WMM(Mic Version) · IP, SIP and ONVIFOutput power60WFrequency response65-20kHzPower supplyPOE/DC24V
EQ-342Lucky ToneSIP Ceiling Speaker with MicrophoneIPC-615SM/IPC-615SPOEM · IP, SIP and ONVIFFrequency response100Hz~18KHzDimensionsDia 200 x 90 mmPower supplyDC 12V/DC 24V or POE05Talk to us
