8-CH 4 Zone Stereo Network Amplifier

Name: Lucky Tone 8-CH 4 Zone Stereo Network Amplifier WF-850 Z4
Brand: Lucky Tone

ModelWF-850 Z4

WF-850 Z4 is a multi-room system that enables you to enjoy your favorite music anywhere in your home. This model contains 4 audio amplififiers for you to connect to 4 set of stereo speakers.

PriceOn request

Request a quotation Discuss your project

Prices on request. We confirm the configuration, availability and lead time for each project; quotations exclude installation, programming, freight and VAT unless agreed otherwise.

01Models2 models in the family

Models compared.

Model		WF-850 Z4
Power RMS		8*50W, 4 Zone Stereo
	Line in	Max 2V RMS input
Audio input	Optical in	Max 192kHz/24bit sample rate decode PCM encoding
Audio input	USB	USB disk drive playback
Audio output	Pre out	Max 2V RMS input
Audio output	Coaxial out	44.1Khz/16bit output
Audio output	Speaker out	50W per channel @ 8ohm, Bridged amplifier mode 100W @ 4ohm per channel
		Master Input Source
Audio Input	Line in	Max 2V RMS input
Audio Input	Optical in	Max 192kHz/24bit sample rate decode
Audio Input	Coaxial in	PCM encoding
		Network
Ethernet In	Rj45	Connect to internet
Ethernet Out	Rh45	Output to other device to share the network
		Music Sources
Streaming Protocol		Spotify Connect, Airplay, DLNA, UPnP, Qplay Spotify, Tidal, Deezer, Qobuz, Naspter, Pandora, Amazon Music,
Online Music		Internet Radio, iHeartRadio, vTuner
Local Music		Mobile device music, NAS storage music files, USB disk drive music files
Multizone Function		1.By Master input source 2.By APP to setup one zone as master to sync music to other zone
		General
Power		115-230V AC 50/60Hz
Control Interface		Dual-way RS232
Size		2U rack size

02DescriptionManufacturer's description

What it is.

Description

WF-850 Z4 is a multi-room system that enables you to enjoy your favorite music anywhere in your home. This model contains 4 audio amplififiers for you to connect to 4 set of stereo speakers. Each zone also contains analog and digital audio outputs for you to use as audio source. You can easily play music from online music services, your phone storage, Spotify and other sources by using Muzo Linkplay app on your iOS or Android device.

Features

1.Amplifification: Each zone can provide 50Wx2@8ohms (stereo mode) or 100W@4ohms (bridge mode)
2.Multi-room audio function: Play different songs in different rooms or same song in every room.
3.Easy network setup: Connect to your home network and it is ready to use.

4.Rich I/O interface: Each zone has separate digital input/output and analog input/output. There is also a master source input that all zones can used at the same time.

03Documents1 file · 2.3 MB
