Sheet 05.129
Lucky Tone · Loudspeakers
Classroom/Presentation Wooden Wall Speakers
ModelWW-104 / WW-105T
The cabinet is made of high-quality fiberboard and birch cold-pressed leather, which eliminates the resonance sound of the cabinet and is suitable for indoor use;
- Weight
- WW-104: 2kg; WW-105T: 2.1kg
PriceOn request
Prices on request. We confirm the configuration, availability and lead time for each project; quotations exclude installation, programming, freight and VAT unless agreed otherwise.
Classroom/Presentation Wooden Wall SpeakersPrice on requestRequest a quotation
01Models2 models in the family
Models compared.
| MODEL | WW-104 | WW-105T |
|---|---|---|
| Power at 100V | 10W | 15W |
| Power at 70V | 5W | 7.5W |
| SPL( 1W/1M) | 92dB | 92dB |
| Max SPL@ 1M | 99dB | 100dB |
| Freq. Response | 90-18KHz | 80-19KHz |
| Product Size | 205×302×115mm | 205×302×115mm |
| Installation | Wall mount | Wall mount |
| Enclosure Material | wood | wood |
| Weight | 2kg | 2.1kg |
| Finish | Black | Black |
| Speakers | 4.5″×1 woofer | 5.25″×1 woofer,1″×1 Tweeter |
02DescriptionManufacturer's description
What it is.
Producing clear, bright and thorough sound;
Elegant outlook
Input voltage 70V / 100V optional
Ordering code
WW-104
10W passive speaker at 100V line, 4.5 inch full range driver
WW-105T
15W passive speaker at 100V line, 5.25 inch bass and 1 inch treble driver
WW-104A
2*15W speaker in pair; 110-240VAC power supply
WW-104A UHF
2*15W speaker in pair; 110-240VAC power supply with one head worn UHF mic
WW-104A IP
2*15W speaker in pair; 110-240VAC power supply with IP net
WW-104A SIP
2*15W speaker in pair; 110-240VAC power supply with SIP net
WW-105TA
2*25W speaker in pair; 110-240VAC power supply
WW-105TA UHF
2*25W speaker in pair; 110-240VAC power supply with one head worn UHF mic
WW-105TA IP
2*25W speaker in pair; 110-240VAC power supply with IP net
WW-105TA SIP
2*25W speaker in pair; 110-240VAC power supply with SIP net
03Documents1 file · 4.7 MB
Documents and files.
Datasheets, manuals, drawings and certificates as the manufacturer publishes them.
