5″ Marine Ceiling Speaker
ModelCP-525
● Water and corrosion proof for outdoor and marine
- Weight
- 0.7Kg
What this product is, in numbers.
The manufacturer's published values. We confirm the configuration and the values that matter for your project before an order.
01Specifications13
- MODEL
- CP-525
- Power at 100V
- 25W
- Power at 70V
- N/A
- SPL (1W/1M)
- 90dB
- Max SPL@1M
- 103dB
- Freq.Response
- 100Hz-20KHz
- Cutout Size
- Dia 122mm
- Product Size
- Dia 165mm
- Installation
- Inceiling
- Enclosure Material
- ABS
- Weight
- 0.7Kg
- Finish
- White
- Speakers
- 1″ x 1 (TREBLE) 5″ x 1 (BASS)
Show the full specificationHide the rest of the specification0 more groups · 0 values
What it is.
● ABS ceiling speaker
● IP44 rating
Lucky Tone 2016
