Sheet 05.376
Lucky Tone · Public address
16-channel 24VDC Supply
ModelD-DCPS16
● Manage 16 loudspeaker line overriding Public Address broadcast by output 24 VDC
- Dimensions
- 133(H) x 483(W) x 390(D) mm
- Weight
- 9.1kg
PriceOn request
Prices on request. We confirm the configuration, availability and lead time for each project; quotations exclude installation, programming, freight and VAT unless agreed otherwise.
16-channel 24VDC SupplyPrice on requestRequest a quotation
01SpecificationManufacturer's data · 1 group · 9 values
What this product is, in numbers.
The manufacturer's published values. We confirm the configuration and the values that matter for your project before an order.
01Specifications9
- MODEL
- D-DCPS16
- Output
- 16 channels 24V DC, 1A
- Trigger Out
- Low level(0V)or short circuit signal
- Controls
- Power switch and address dip setting
- Indicators
- POWER,CH1 ~ Ch16
- Protection
- AC fuse: 6A
- Power Requirement
- AC 220V ± 10% 50-60Hz; 24VDC
- Dimensions
- 133(H) x 483(W) x 390(D) mm
- Net Weight
- 9.1kg
Show the full specificationHide the rest of the specification0 more groups · 0 values
02DescriptionManufacturer's description
What it is.
Features
● Activated by a 16-channel input and the input alarm signals control the 24V power source outputs.
● Can work with volume control and other emergency activating devices
